260VA medical safety transformer

Amplimo 7N667

part number: 7N667

in stock

€ 132.00 (inc VAT)
Amount:

Specifications :

  • Typenumber : 7N667
  • Power rating : 260VA
  • Primary windings : 2x115V
  • Static screen between primary and secondary windings
  • Secondary windings : 2x 115V - 1.13A
  • Builtin selfresetting thermal cutout
  • Secondary windings in series gives : 230V - 1.13A
  • Secondary windings in parallel gives : 115V - 2.26A
  • Diameter : 122mm
  • Height : 57mm
  • Mounting materials are supplied in the shipment

Downloads:

Download datasheet 7N667 (PDF)





  • Kema Keur
  • ENEC
  • UL/CSA approved
  • IEC601
  • 50/60Hz
  • 115v
  • Thermal Cutout 120C
  • RoHS Compliant
  • dubbel geisoleerd
  • Isolating Transformer
  • Tapescreen
